How to measure a pipe flange size?

To measure the size of a flange, you will need a measuring tape or a ruler. Follow these steps:

1.Measure the outside diameter (OD) of the flange: Place the measuring tape or ruler on the outside edge of the flange and measure across the widest point. Make sure you are measuring across the entire diameter, including any protruding lips or bolts.

2.  Determine the bolt hole diameter (BHD): Measure the distance between the center of two opposite bolt holes. Repeat this measurement for all bolt holes and take an average to get the BHD.

3.  Count the number of bolt holes: Count the number of bolt holes in the flange. This is important to know for selecting the correct gasket and bolt pattern.

4.  Determine the bolt circle diameter (BCD): Measure the distance between the center of one bolt hole to the center of the bolt hole directly opposite it. Multiply this measurement by the number of bolt holes to get the bolt circle diameter.

5.  Identify the flange standard: Flanges come in different standards such as ANSI, DIN, JIS, and others. Identify the standard to ensure that the flange will fit with other components in the system.

By following these steps, you can accurately measure the size of a flange.
